Gavita B200 Booster Module
$150.00
- Dedicated for Gavita Master Controller EL-1 / EL-2
Standard, a Gavita Master Controller port can drive 40 fixtures. For larger rooms we offer a distributed solution, based on our B200 booster.The B200 booster has one input and 4 buffered outputs, each capable of driving 50 e-series fixtures. So in total 200 fixtures can be connected to one booster.Three boosters can be connected to one Master Controller EL output, allowing for a total of 600 fixtures per port to be controlled. The two port EL2 therefore can control 1200 e-series fixtures in total.The B200 EL booster module come with 4 5m/16ft controller cables that enable you to branch your lighting installation from the 4 booster outputs.
Specifications
| Power input | Gavita Master Controller only (15 V DC) |
|---|---|
| Controller input | RJ12 |
| Ballast output | 4 x RJ9, 50 ballasts per channel 200 ballasts total |
| Housing | Extruded aluminium, Black anodized Laser printed |
| Warrenty | 3 years |
| Model | B200 US (only available in US) |
| Article Number | 90.02.02.04 (US 120V) |
| EAN code | 8718403054484 (US 120V) |
Features & Benefits
4 ports driving 50 fixtures each
With every booster you can add another 200 fixtures to a controller port
Maximum of 3 boosters per port
Every controller port can, with 3 boosters connected, drive a whopping 600 fixtures. If you use both ports of the EL2 controller the total would be 1200 fixtures, using 3 boosters on each port.
Divide your room lights
By centrally distributing different rows of light through a booster you can easily control which lights need to be on
8 in stock
